Power Systems

Rated power: 250W,
Voltage/frequency: AC110－240V/50-60HZ

Control System

Control protocol: International standard DMX512 control protocol.
Control channels: 6 channels.
Control mode: DMX mode, random mode, auto mode, and voice control mode, which can be freely selected.

Optical system

Light source brand: using high-quality, high-brightness brand LED light source
Light source power: LED 200W, respectively: 100W warm white +100W cold white.
Beam angle: optical reflector, standard 50°

Color system

Color mixing effect: uniform W+Y non-polar color temperature mixing system,
Special function: Built-in a variety of lighting effect programs, which can be separated from the console, and the sound control runs synchronously.

Dimming system

1. Strobe: high-speed electronically adjustable strobe up to 1-25 times per second or random strobe
2. Dimming: The total dimming channel can simultaneously control the light and dark changes and closed the light of the 2 main colors at the same time

Cooling system

Environment temperature: -10℃—60℃

lighting design

1. Internal design: In accordance with international standards, it integrates the powerful design strength of Dage Lighting, is made of new high-quality materials, and has independent lamp body design patents. Counterfeiting must be investigated.

2. Appearance design: Humanized multi-module structure, using high-quality and high-strength cooling forming die-cast aluminum alloy core material structure, with independent appearance design patent, counterfeiting must be investigated.


Remarks: We do our best to provide you with accurate and comprehensive product information. Product design specifications are subject to change without notice. Please refer to the actual product for details. Dage Lighting reserves the right of final interpretation.
