Overview

★This is DAGE exclusive product: with R & D and design patents, any Infringement and Counterfeits will be prosecuted.★


MAIN FEATURES:
Smart and unique housing deign with casing patent
450w 380v integrated power supply, 36V, 24V, 12V dedicated voltage, with super accurate positioning and strong anti-interference ability
1 color wheel 13 colors+open, 1 fixed gobo wheel with 10 gobos+open
Fantastic & colorful honeycomb 8+24 facet prism
Sensitive & high speed, 3-phase motor for X/Y movement
The integrated folding hooks, the built-in battery is not powered to encode the address, the RDM console can encode the address code, and the prism automatic adjustment function is convenient and fast.

OPTICAL SYSTEM
Osram 295w bulb, 7200k, 2000hs life
Reflect bowl is coated with multi-layer, efficiency and reflective coating
Italian heat-protecting glass, good dissipation
Optical lens dia. 132mm, the beam uniform, sharpy, bright
1.5-2° beam angle
Electronic focusing
DISPLAY SYETEM
Display mode: button-type display, stable and durable; built-in self-rechargeable buffer battery, can edit menu in no power state; the screen can display upright, inverted, and the brightness adjustment of the background; it can display the use time of bulb and fixture.
With Automatic error tested function
Debugging device: In order to facilitate the use of manufacturers and users, you can enter through the advanced settings of the menu and password to debug the functions of the horizontal, vertical, focus, strobe, color disk, pattern disk, and prism disk.
CONTROL SYSTEM
International standard DMX512
22 control channels.
DMX, random, auto, voice mode.
Using high-tech constant current board, 36V / 12V voltage
Built-in high -quality magnetic components ensure stable signal transmission
Data line antifreeze, in line with CE20 / 22 standard
3 XLR or 5 XLR In&Out options
POWER SYSTEM
450w, power fluctuations (± 50W) works normally
AC90-260V, 50-60HZ,
Using high-tech constant current power board, first-class brand PCB components,  AC voltage mode
Ground wiring in accordance with international standards
Built-in high -quality lighting power filter to ensure stable signal transmission
Power line antifreeze, in line with CE20 / 22 standard
STROBE SYSTEM
Independent double shutter device, 0-14 times/s
0-100% linear dimming
The lamp power is automatically reduced by 30% when it turns off in 5 seconds
Remote control switch and boot light function for bulb, default as remote control
COLOR SYSTEM
Imported Italian specialty high temperature materials, Germany's high-tech coating technology
13 colors + open
Semi- color, full-color, single-color gradients, changeable fast forward and reverse direction rotating rainbow effect
Automatic error correction at any angle with hall, magnet positioned
GOBO SYSTEM
10 patterns + open+flowing pattern, 4 glasses adjustable beam angle,
enabling water, shake, slow-fast rotation effect
Imported Italian specialty refractory metal materials
Automatic error correction at any angle with hall, magnet positioned
FROST SYSTEM
Frost setting: Independent single-sided high penetration frost lens
Frost effect: Achieved various changes of frost effects from color and gobo wheels
Frost angle: The largest is 50°
PRISM SYSTEM
Prism Material: Italian heat-protecting glass. Germany's high-tech coating technology
Prism structure: Unique honeycomb 24 & 8 facet prism, honeycomb+ 8 facet prism, can overlap 32 prism effect at the same time
Rotating angle is adjustable. The largest prism angle is 50°
Auto-focusing
COOLING SYSTEM
Excellent aluminum material, good heat dissipation and light weight
Number of fans: The base of the lamp is set with a silent cooling fan; the light bulb system is set with 4 silent fans, the fan is intelligently regulated, and the heat dissipation is completely controlled intelligently according to the use status and requirements of the light bulb to ensure that the entire lamp body is always kept within the predetermined temperature range.
Thermal protection: Built-in overheating protection
ROTATION SYSTEM
XY motor: Fast and quiet 3-phase motor
XY position: Encoder& Hall components position and advanced scanning memory function
Pan:540°（16/32 bit)
Tilt 260 °（16/32 bit)
LIGHTING DESIGN
Metal Plate: creative high quality raw material
Housing design: user-friendly, nice looking, tough and neat
size and weight
Body size: 31 × 33 × 55 (cm), net weight: 18.5 kg
Carton size: **× **× **(cm) , G/W: ** kg
Flight case 2 in 1: **× **× **(cm) , G/W: ** kg
Lighting attachment
1pc User manual; 1pc insurance rope; 1 pair powercon; ; 2 aluminum alloy lamp hooks; 3 meters of signal cable; 1.5 meters of power cable.


REMARKS: DAGE lighting reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
