Overview

DG-3303 Cannon King Follow Spot Light 330W 15R


PRODUCTION DESCRIPTION:

DG-3803 Cannon King is a small size, low power, long life, high brightness follow spot light, it combines high-quality materials from foreign country and DAGE’s exquisite design technology, 50W 380V power supply with 12v, 5V voltage, which has strong anti-jamming capacity;own R & D dedicated optical lens, high strength concentrating effect; with 5 colors + white; linear manual angle adjustment, the opening angle from 2.8-30°, the adjustable color temperature can meet both follow spot and color washing effect in the event, Inheritance DAGE decades of professional quality skills, with rich, superior hardware facilities and production processes, to implement global quality standards and strict quality control system, so that the light is consistent performance and quality, unique charm always!


OPTICAL SYSTEM
OSRAM SIRIUS HRI 380W, color temp:7,000K
Custom reflect bowl, 3 groups optical lens, using anti-heat material, all coated with multi-layer, efficiency and reflective coating
Beam angle 2.8-30° , manual linear zoom, unique optical design, uniform light spot to reach any range, with the center and the edge region brightness difference is not more than 20%
POWER SYSTEM
450w, power fluctuations (± 50W) works normally
AC90-260V/50-60HZ
Using high-tech constant current power board, first-class brand PCB components, SMT processing technology, AC voltage mode
Ground wiring in accordance with international standards
Built-in high-quality lighting power filter to ensure stable signal transmission
Power cable antifreeze, in line with CE20 / 22 standard
COLOR SYSTEM
Imported Italian specialty high temperature materials, Germany 's high-tech coating technology
5 color +open, changeable color wheel
Color temperature from 7000k-2700k manual adjustment
DIMMING SYSTEM
The shutter 0-100% adjustment; 2, Iris 5-100% linear adjustment
COOLING SYSTEM
Excellent aluminum material, quite, good heat dissipation and light weight
Fan Qty: 2pcs
Built-in overheating protection
ROTATING SYSTEM
Pan: 360°
Tilt: 90°
FIXTURE DESIGN

New high-quality alloy
The sides of the fixture are designed with four control handle, the rear cover is designed with a main control handle
Structure design, with international standards, integrate DAGE’s strong design strength, with our own light body design patents


Remarks: Based on our ongoing product improvement, the data contained in this manual may change, and there will be no further notice, the company has the power to improve the relevant specifications, any inconvenience, please understand
